Single lumen laryngeal mask airway-Reinforced
Single lumen laryngeal mask airway-Reinforced
Product Category: PVC laryngeal mask airway
view: 6134
inquiry

Parameters Download

Disposable Laryngeal Mask Airway (Reinforced):

1. It is made of medical grade PVC raw materials, so has good biocompatibility.

2. The capsule is under all-in-one molding, such craft could improve the safety of products.

3. The capsule is better balanced on both sides of the force after air inflation,  the transition between the cuff and the tube is smooth, there is no obvious concavity on the connection, such details could reduce body damage.

4.  There are 2 types, with/without the blocker, the blocker could prevent the backflow of the foreign matter.

5. The stainless steel spring is built into the pipe to prevent the tube body from buckling and twisting to generate a closed gas;

6. Suitable for a variety of patient positions, especially lying position;





【Specifications】





size

Maximum aeration

Patient weight (KG)

1.0

4ml

0-5

1.5

7ml

5-10

2.0

10ml

10-20

2.5

14ml

20-30

3.0

20ml

30-50

4.0

30ml

50-70

5.0

40ml

70-100


【Description】


   The middle part of the tube is reinforced to prevent teeth from biting. It is smooth and soft, high transparency, excellent flex resistance. Suitable for adults, children, newborns

【Feature】

   1. It was made of medical grade PVC material, so has good biocompatibility, non-toxic and non-irritating.
   2. The mask is made of  soft PVC and designed according to the outline of laryngeal, it maximally reduced the stimulation to human body and increase the sealing property.
   3. The reinfored type laryngeal mark is used for head and neck surgery on ear/nose/throat/ eye/oral part.
   4. Reinforced steel wire tubes have excellent kink and flex resistance, could prevent teeth from biting and breaking.
   5. There are complete specifications which can be used for newborns/children/adults.
